Wrought Iron Curtain Pole Measuring Guide


Curtain Pole Measuring Guide

Click here to measure for traditional wrought iron curtain poles

Traditional curtain poles with two finials

Click here to measure for traditional wrought iron curtain poles

Solid cottage poles with two finials

Click here to measure for traditional wrought iron curtain poles

Traditional curtain poles with one finial

Click here to measure for traditional wrought iron curtain poles

Traditional curtain poles with no finials

1. How to order a traditional wrought iron curtain pole with two finials

Use section 2 for solid cottage poles

wrought iron curtain pole measuring guide for straight curtain pole by Nigel Tyas ironwork

1. Choose the diameter of pole - 16mm, 22mm or 32mm - click here to find out more

2. Decide on the length of pole using the diagram above – please DO NOT include the length of the finials in your measurement.

Please note that the 10cm shown is a guide and can be increased or decreased as required.

3. Choose your favourite finial(s) - click here to see our collection of 15 handmade finials

4. Choose the style & number of brackets - click here to read our useful guidelines about choosing your brackets

If you are unsure about the best brackets to use please call, we will be pleased to help. We normally recommend a vertical or horizontal bracket at each end of the pole and a central support bracket for poles between 2m & 3m in length. For longer poles needing more than one support bracket you will need to use hook brackets with open curtain hooks to allow the curtain to run past the supports.

5. Choose curtain rings or hooks if required - click here to see the range

6. Add matching wrought iron holdbacks or tieback hooks if required - click here to see the range

7. Choose Natural Black or Light Burnished Steel surface finish for your curtain pole & accessories - click here to see more


2. How to order a wrought iron solid cottage pole with two finials

Use section 1 for traditional poles

wrought iron curtain pole measuring guide for straight curtain pole by Nigel Tyas ironwork

1. Choose the diameter of solid pole - 12mm or 16mm - click here to find out more

2. Choose your favourite finial design - click here to see the 5 styles of solid forged cottage poles

3. Decide on the length of pole using the diagram above – please DO NOT include the length of the finials in your measurement.

Please note that the 10cm shown is a guide and can be increased or decreased as required.

4. Choose the style & number of brackets - click here to read our useful guidelines about choosing your brackets

If you are unsure about the best brackets to use please call, we will be pleased to help. We normally recommend a vertical or horizontal bracket at each end of the pole and a central support bracket to support longer poles.

5. Choose curtain rings if required - click here to see curtain rings

6. Add matching wrought iron holdbacks or tieback hooks if required - click here to see the range

7. Cottage Poles are normally finished in natural black. If you would prefer our Light Burnished Steel finish, please contact us for more information on 01226 766618 or email sales@nigeltyas.co.uk - click here to see more


3. How to measure for a traditional pole with one finial and one end fitted to an adjacent wall

wrought iron curtain pole measuring guide for a single recess curtain pole by Nigel Tyas ironwork

1. Choose the pole, finial, rings and finish as described above.

2. Decide on the length of the pole using the diagram above – please give us the total overall length required from the wall INCLUDING the finial and EXCLUDING the depth of the single recess bracket.

Please note that the 10cm shown is a guide and can be increased or decreased as required.

3. Choose a single recess bracket to fit the non-finial end of the pole and other bracket(s) as above - click here to read our useful guidelines about choosing your brackets


4. How to measure for a traditional pole without finials and with each end fitting onto an adjacent wall

wrought iron curtain pole measuring guide for double recess curtain pole by Nigel Tyas ironwork

1. Choose the pole, rings and finish as described above.

2. Decide on the length of the pole using the diagram above – please give us the overall width of the recess EXCLUDING the depth of the double recess brackets - we will make the necessary adjustment to allow for the depth of the brackets.

3. Choose a double recess bracket for each end of the pole and a central support bracket if required - click here to read our useful guidelines about choosing your brackets

IMPORTANT NOTE : Please take the measurement as close as possible to the position where you would like the brackets to fit to the wall. It is surprising how much the width of a recess can vary from top to bottom and this can be enough to prevent a precision made pole from fitting!


... and finally, if you need more help choosing ...

... we're are always happy to talk about your requirements and to offer advice on ordering. If you need curtain poles for a non-standard window, we can advise on the measurements needed and provide an obligation free quotation - Just call Sheena or Sam on 01226 766618 or email sales@nigeltyas.co.uk
